5.5kw 5.5kva Solar Hybrid Inverter Charger 24V 48V DC To 220V AC Pure Sine Wave

Place of Origin : Guangdong, China

Model Number : SUF5000S4A1

Brand Name : SZSSTH

Price : CN¥1,747.07/pieces 1-99 pieces

Input Voltage : 48V

Output Voltage : 220V 230V

Output Current : Load

Output Frequency : 50Hz/60Hz

Output Type : Single

Size : 300*450*110.5mm

Type : DC/AC Inverters

Inverter Efficiency : 93%

Weight : 8kg

Product name : 5.5KW Hybrid Solar Inverter

Inverter type : Hybrid Off Grid Solar Inverter

Controller type : MPPT Solar Controller

Communication : WiFi/GPRS(Optional)

Battery type : Lead Acid \ Lithium

Protection : Overload

Rated power : 5.5KW

AC Voltage : 230VAC

Display : LCD Display

Max PV voltage : 500V

Certificate : CE, ROHS

Warranty : 1 year

Contact Now

5.5kw 5.5kva Solar Hybrid Inverter Charger 24V 48V DC to 220V AC Pure Sine Wave MPPT Solaire Hybride Invertor

Products Description
5.5kw 5.5kva Solar Hybrid Inverter Charger 24V 48V DC To 220V AC Pure Sine Wave
5.5kw 5.5kva Solar Hybrid Inverter Charger 24V 48V DC To 220V AC Pure Sine Wave
Product Features
Product Features
1. Pure sine wave solarinverter
2. Built-in40AMPPT solar charger
3. PVinput voltage range 20~150VDC (for 1000W),30~150VDC(for 1500W)
4. Built-in anti-dust kit for harsh environment
5. Smart battery charge design to optimize battery lifemeet rich customizeddemands
6. Solar energy is provided directly to the load first
SUF3000S4A1
SUF5000S4A1
BatteyInput
Battery Type
Li-lon/Lead-acid
Li-lon/Lead-acid
BatteryVoltage
24Vdc
48Vdc
Inverter Output
Nominal Power(W)
3000
5000
Nominal Apparent Power (VA)
3000
5000
Paralll Capacity
No
Yes.9 units maximum
AC Voltage Regulation (Battery Mode)
230Vac±5%@50/60Hz
230Vac±5%@50/60Hz
Surge Power (VA)
6000
10000
Eficiency (peak)
93%
93%
Waveform
Pure sine wave
Pure sine wave
Transfer Time
10ms (for personal computers), 15ms (for home appliances)
SolerCharge
Max.PV Array Power (W)
4000
6000
MPPT Range @OperatingVoltage
120Vdc-430Vdc
120Vdc-430Vdc
Number of Independent MPP Trackers
1
1
Number of Strings Per MPPT
1
1
Max,Input Current Per MPPT(A)
16
18
Max.PV Array Open Circuit Voltage (V)
500Vdc
500Vd
Max Solar Charge Current (A)
120
80
Ac Charger
Max.AC Charge Current(A)
120
80
AC Input Voltage (V)
230Vac
230Vac
Voltage Range (V)
170-280Vac (For PersonalComputers); 90-280 Vac(For Home Appliances)
Frequency Range(Hz)
50/60
50/60
General
UserInterface
APP+LCD Display+LED
Communication
USB,Optional:Wi-Fi,4G,GPRS,RS485/CAN,Dry-contact
Ingress Protection Rating
IP54
IP54
Dimension (W*H*D mm)
300*450*110.5
300*450*110.5
Weight (kg)
7.5 8
Relative Humidity
20%~95%
20%~95%
Max.Operating Altitude (m)
2000m, >1000m derating
2000m,>1000m derating
Operating Temperature (°C)
0~50
0~50
Storage Temperature (°C)
[-15~60]
[-15~60]
Protection
PV Over VoltageProtection
Yes
PV Over Current Protection
Yes
Battery Over Voltage Protection
Yes
Battery Over Current Protection
Yes
AC Surge Protection
Type II
Output OverCurrentProtection
Yes
Output Short Circuit Protection
Yes
Output OverVoltage Protection
Yes
